Juice Bottle Mold
NDA Protected We rigorously enforce Non-Disclosure Agreements for all OEM/ODM projects. All proprietary designs and specifications shown herein are displayed with explicit client authorization.
Juice Bottle Mold Case
Technical Specifications
Product Parameters
- Bottle Capacity
- 450 ml
- Neck Finish
- 38mm
- Preform Weight
- 28 g
- Cavity Number
- 4 Cavities
Mold Configuration
- Mold Material
- 7075 aluminum
- Machine Brand
- Rotary Blow Molding Machine
- Material Saving
- 2g
- Project Type
- Beverage
From Preform to Final Product
How we turned a concept into reality. By optimizing the preform-to-bottle relationship, we ensured the final container is lightweight, durable, and cost-effective.
Preform Matching
We analyzed the neck finish and gram weight (e.g., 120g) to ensure the preform has the correct stretch ratio for uniform wall thickness.
3D Design & Simulation
Engineered for max strength and comfort. Simulation verified to prevent deformation during blowing.
Precision Molding
Manufactured with 7075 Aluminum/S136 Steel for fast cooling. The result is a high-clarity bottle produced with a stable cycle time.
The Engineering
Standards Behind This Case
It's not just about the bottle shape. We ensure this mold delivers profitability through speed, durability, and seamless integration.
Request Technical SpecsCycle Time Optimization
We engineered custom conformal cooling channels for this project, reducing the cooling time by 15% compared to standard molds. This means higher daily output for you.
Certified Steel Lifespan
Built with vacuum-hardened S136 Steel. We guarantee this mold maintains high-gloss bottle finish and precision parting lines for over 6 million shots.
Seamless Machine Fit
PLUG & PLAY100% compatible with your Linear/Rotary machine. We provide specific installation guides and process parameters to ensure a "Plug & Play" startup.
Ready to Scale Your
Production Line?
Don't let inefficient tooling slow you down. Get a technical consultation and precise quotation for your S136 PET molds today.
Fast Response
Technical quote within 24 hours
Factory Direct
No middleman markups
